High Pressure Piston 30bar Natural air Compressor
High pressure piston 30bar natural air compressor
1. Main data
Equipment Model | Free Air Delivery (M3/min) | Pressure (Bar) | Power (Kw) | Rotating speed (r/min) | Size(mm) | Weight (Kg) |
| 4-WH-6.0/30 | 6.0 | 30 | 4*18.5 | 790 | 2020*1570*200 | 3500 |
Model | Air capacity (M3/min) | Working pressure (Bar) | Power(Kw) | Speed(r.p.m) | Weight(Kg) |
VH-0.7/30 | 0.7 | 30BAR | 7.5 | 680 | 310 |
WH-1.0/30 | 1.0 | 11 | 600 | 430 | |
WH-1.2/30 | 1.2 | 15 | 760 | 450 | |
WH-1.5/30 | 1.5 | 18.5 | 790 | 520 | |
WH-2.0/30 | 2.0 | 22 | 670 | 610 | |
WH-2.35/30 | 2.35 | 25 | 760 | 620 | |
2-WH-3.0/30 | 3.0 | 2*18.5 | 790 | 1150 | |
3-WH-3.6/30 | 3.6 | 3*15 | 700 | 1580 | |
VH-0.17/35 | 0.17 | 35BAR | 2.2 | 660 | 110 |
VH-0.65/35 | 0.65 | 9.0 | 605 | 420 | |
WH-1.1/35 | 1.1 | 15 | 900 | 475 | |
WH-2.0/35 | 2.0 | 22 | 670 | 615 | |
WH-2.2/35 | 2.2 | 25 | 735 | 600 | |
VH-0.3/40 | 0.3 | 40BAR | 5.5 | 500 | 290 |
WH-1.0/40 | 1.0 | 11 | 790 | 470 | |
49SH-2.6/40 | 2.6 | 25 | 625 | 900 | |
49SH-3.0/40 | 3.0 | 30 | 695 | 920 | |
2-49SH-6.0/40 | 6.0 | 2*30 | 695 | 2100 | |
4-WH-4.0/40 | 4.0 | 4*11 | 790 | 2400 | |
6-WH-6.0/40 | 6.0 | 6*11 | 790 | 3600 |
2. Inspection method:
CAGI
3. Inspection standard:
-AISI
-AMS
-ANSI
-ASME
-ASTM
-AGMA
-AGMA
-NEMA
-VDI
-CAGI-NPEUROP
-MS
4.High pressure air compressor
- The compressor can remove waste and dirt automatically by after cooling system. High-quality air out end with a special, highly effective air cooling chiller of advanced design.
- Market leader “Herbiger” main air valve with large capacity. Its high efficiency characteristic ensures the stable running of the compressor.put due to economical dirt removal system in 3 stages.
- The compressor is equipped with a special,highly effective air cooling chiller of advanced design
5.ELECTRICS FOR MACHINES
If the equipment fails due to the quality of the machine during one year, we will provide replacement and the repair Free of Charge. after One Year customer must pay for Spare Parts, we will provide long-term technical assistance.
Workers must operate the machines according to the design of the machine. Faygo Machinery will not be responsible for accidents which are caused by improper operation of workers.
