FK816 Hot Selling Full Automatic Box Corner Anti-counterfeiting label on corner sealing top/side corner label Machine
FK816 Automatic Corner seal labeler
FK816 is suitable for all kinds of specifications and texture box such as phone box, cosmetic box, food box also can labeling plane products.
FK816 can achieve double sealing film labeling, full coverage labeling, partial accurate labeling, vertical multi-label labeling and horizontal multi-label labeling, widely used in cosmetics, electronic, food and packaging materials industries.
|
Parameter |
Data |
|
Label Specification |
Adhesive sticker, transparent or opaque |
|
Labeling Tolerance(mm) |
±1 |
|
Capacity(pcs/min) |
100 ~150 |
|
Suit bottle size(mm) |
L:40~250; W:40~200; H:10~100; Can be customized |
|
Suit label size(mm) |
L:10~70; W(H):10~70 |
|
Machine Size(L*W*H)(mm) |
≈1100*700*1450 |
|
Pack Size(L*W*H)(mm) |
≈1700*1200*1500 |
|
Voltage |
220V (Can be converted) |
|
Power(W) |
950 |
|
N.W (KG) |
≈160 |
|
G.W(KG) |
≈200 |
|
Label Roll |
ID: Ø76mm;OD:≤300mm |
|
Basic Application
|
*For all kinds of production line labeling. *Widely used in food, cosmetic, chemical, pharmaceutical and other industries. *Date printer can be added to print production date,batch lot and expiry date while labeling. *Support customization.In stock. |
