0.1-2L Semi auto PET bottle stretch blow molding machine with 2 Cavity
FOB Reference Price
Purchase quantity ()
Minimum order quantity
Payment
ShenZhen J&D Drinking Water Equipment Co.,Ltd.
China - Shenzhen
Manufacturing and trade
Trade Capacity
Export Percentage
90-100%
Nearest Port
SHENZHEN,SAHNGHAI
Accepted Delivery Terms
FOB
Employees
11-50 people
Accepted Payment Currency
USD
Average Lead Time
90 Day(s)
Certifications
CE
Product Specifications
Application
Film
Plastic Processed
PET
Blow Moulding Type
Stretch Blow Moulding
Product Description
Application
The reheat stretch blow molding machine is designed according to CE standard.
Accurate and stable parameter control for the adoption of microcomputer controlling system.
Simple and safety operation; and only one operator is needed.
JNDWATER JND-880 Semi-auto Reheat Stretch Blow Molding Machine is suitable for manufacturing carbonated beverage bottles, mineral water bottles, cosmetics bottles and hot-filling bottles, especially bottles with handles and so on，the series machine has 2 cavities and albe to meet production requirements.
Technical Parameters
| Model | JND-880 | JND-880H |
| Clamping Force | 80KN | 80KN |
| Number of Cavities | 2 | 2 |
| Theoretical Output | 0.5L:880BPH | 0.5L:600BPH |
| Mould Open Stroke | 150mm | 150mm |
| Max. Mould Thickness | 200mm | 200mm |
| Space Between Tie Bars | 340*500mm | 340*500mm |
| Electrical System | ||
| Voltage Standard | 380V/3PH/50HZ or special order | |
| Total Power(Full Loaded) | 7kw | 15kw |
| Container | ||
| Max. Container Volume | 0.1-2.5L(2cav) | 0.1-2.5L(2cav) |
| Max. Container Diameter | 110mm | 110mm |
| Max. Container Height | 360mm | 360mm |
| Auxiliary System | ||
| Low Air compressor | 8-10Bar | 8-10Bar |
| High Air compressor | 30Bar | 30Bar |
| Dimension & Weight (L×W×H) | ||
| Blow molding machine | 1500*600*1750mm | 1500*600*1750mm |
| Preform Auto loader | 1800*630*1380mm | 1800*630*1380mm |
| Net Weight | 0.82Ton | 0.93Ton |
Product advantages
All the machines’s electronic component which product by ShenZhen J&D Drinking Water Equipment Co.,Ltd. come from famous manufacturers all over the world ,such as Omron,Siemens and so on.
Product by CE standard.
Our Service
After the machines arrives at the customer's factory, ShenZhen J&D Drinking Water Equipment Co.,Ltd. can arrange engineers to customer's factory to install and debug the equipment, make the machines run to the best working condition;the engineers also can train customer's staff about how to operation and maintenance of the equipment, customers also can arrange their engineers to study in our factory for free . During the warranty period,we provide the easy damage parts for free.
